Silica aerogel is currently recognized as one of the most effective thermal insulation materials. The pore diameter of aerogel is smaller than the mean free path of air molecules, causing the air within the pores to remain almost static, thereby eliminating heat loss caused by air convection. In addition, the low density and nanoscale tortuous network structure of aerogel effectively block heat transfer through both solid and gaseous phases. Moreover, the enormous number of pore walls within the aerogel structure minimizes thermal radiation to an extremely low level.
Based on these three mechanisms, silica aerogel effectively suppresses all major modes of heat transfer, providing superior thermal insulation performance compared with conventional insulation materials.
· Superior thermal performance:
Silica aerogel has extremely low thermal conductivity. Its insulation performance is approximately 3–5 times better than that of traditional insulation materials, significantly reducing heat loss while saving installation space.
· Fireproof and waterproof:
The product meets Class A non-combustible fire rating standards. Its hydrophobic rate exceeds 99%, providing excellent water resistance while still allowing water vapor permeability.
· Heat-resistant and durable:
Aerogel has a three-dimensional network structure that differs from conventional insulation materials. This structure effectively prevents sintering, deformation, and particle aggregation during long-term high-temperature exposure, ensuring a long service life.
· Sound insulation and shock absorption, environmentally friendly.
· Easy installation:
The product is thin, lightweight, and low in density, with good tensile and compressive strength. It is easy to cut and install, offering high construction efficiency.
· Long service life:
Aerogel is an inorganic material with excellent resistance to aging and weathering. It maintains good flexibility and tensile strength. Accelerated aging tests indicate a service life of more than 20 years.
Type | Q650 | Q450 | Q350 | Q200 | Q100 | ||||
Size(mm) | 38/36/27m x 1.5m x3/6/10mm | ||||||||
Density(kg/m³) | 200±10 | ||||||||
Serving Temp | 350-650 | 200-450 | Environment Temp.to 350 | -200-200 | -200-100 | ||||
Application | Hot Insulation | Hot Insulation | Hot Insulation | Hot / Cold Insulation | Insulation | ||||
